HomeProducts Multilayer Foil Quilt Thermal Insulation Blanket 15 Layers MultiFoil Dome Heat Insulation
15 Layers MultiFoil Dome Heat Insulation
Contact Us

E-mail: sales2@silpacking.com
Mob/WhatsApp: 0086 135 6679 6337

  • Features
  • Technical Data
  • Application
Clean, lightweight, easy to handle
Environment-friendly and safety
Easy to install, high efficiency
Cost-effective and versatile
Waterproof breathable material, solar heat reflective


Number of components

19 layers

Dimension

1.5m x 10m

Coverage

15m2

Weight

16.5kgs/roll

Strength of woven

MD

600 N/50mm

CD

600 N/50mm

Emissivity of external surface foil

0.03

Reflectivity of aluminum foil

More than 97%

R Value of blanket

Need to consider where and how to use the thermal insulation

Sewing size of stitches

Customized

Position of sewing

2 lines



Roof insulation: The multilayer foil insulation can be used over rafters, under rafters, between and around purlins, as part of a two layers applications and when all joints are sealed using aluminum foil tape can also work as a vapor control layer.



Wall insulation: The multilayer foil insulation can be used with timber frames, cavity walls, dry lining, dwarf walls, dormer cheeks and external walls.



Under floor insulation: The multilayer foil insulation can also be used with suspended timbers, crawl spaces and floating timbers.
